Side Tilt Carriages - There are actually 4 sizings of hook type blade carriages rated by the blade carriage lifting capability. Hook type tine carriages have been the same.
The carriage bar spacing utilized for Class 1 is more or less thirteen inches and the Class 1 carriage is rated to carry loads up to 2000lbs. The Class 2 carriage is rated to carry cargo up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
The carriages for pin type tines can be different depending on the maker. Pin mounted blades can vary by the amount of offset between the blade eye and the blade. Carriage capacity will be established by the carriage pin size and by the tine size.
