Carriage - There are 4 sizings of hook type tine carriages rated by the tine carriage hoisting capacity. Hook type blade carriages have been standardized.
Class I carriages are rated for cargo up to 2000 lbs. The carriage bar spacing for Class I is thirteen inches. Class II carriages are rated for loads as much as 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing utilized for this capacity is twenty five inches.
The carriages for pin type forks may be different depending on the maker. Pin mounted tines could differ by the amount of offset between the tine eye and the blade. Carriage capacity will be established by the carriage pin size and by the tine size.
